DESCRIPTION

· The 154 Series OMNI-BLOK® Fuse and Holder Assembly provides an efficient solution for installing and replacing miniature Nano2® surface mount fuses.

· RoHS compliant and available in tape and reel packaging for easy PCB installation.

· Fuse replacement can be done without exposing the PCB to solder heat, ensuring board integrity.

FEATURES

· Easy fuse replacement with a miniature design.

· RoHS-compliant and halogen-free, meeting environmental standards.

· Offers Very Fast-Acting and Time-Lag fuse options.

· Holder compatible with a range of Nano2® type fuses.

· Wide range of current ratings available: Fast-Acting Fuses (62mA - 10A) and Slo-Blo Fuses (375mA - 5A).

· Heat-resistant fuseholder rated UL94 V-0, capable of withstanding 260°C reflow temperatures.

· Recognized to UL/CSA/NMX 248-1, UL/CSA/NMX 248-14, and UL/CSA/NMX 4248-1 standards.

APPLICATIONS

· Suitable for use in various electronic devices requiring reliable fuse protection.

· Ideal for applications where easy fuse replacement and minimal PCB exposure to heat are critical.

· Can be used in environments with a wide operating temperature range.
