Name: BAP64-04-TP
Brand: Micro Commercial Co
SKU: JM-BAP64-04-TP
Availability: InStock

Micro Commercial Co BAP64-04-TP

View All RF Diodes by Micro Commercial Co

Part Number:
BAP64-04-TP
Manufacturer:
Micro Commercial Co
Category:
RF Diodes
RoHs:
RoHS Compliant
Datasheet:
BAP64-04-TP_Datesheet
Description:
Interface
In stock 0

" Not available to buy online? Want the lower wholesale price? Please send RFQ, we will respond immediately

Leave Us A Message!

[email protected]

We`re not around but we still want to hear from you! Leave us a note:

SEND

*You can contact us directly on WhatsApp!

Specifications

Type

Paramete

Type

Paramete

Capacitance @ Vr, F

0.35pF @ 20V, 1MHz

Current - Max

100 mA

Grade

Operating Temperature

-65°C ~ 150°C (TJ)

Package / Case

TO-236-3, SC-59, SOT-23-3

Power Dissipation (Max)

250 mW

Supplier Device Package

SOT-23

Voltage - Peak Reverse (Max)

175V

Qualification

Diode Type

PIN - 1 Pair Series Connection

Resistance @ If, F

1.35Ohm @ 100mA, 100MHz

Overview

DESCRIPTION

· General Purpose Pin Diodes with a power rating of 250mW.

· Available in models BAP64-04, BAP64-05, BAP64-06.

· SOT-23 package dimensions provided for each model.

FEATURES

· Operating and storage temperature range: -65°C to +150°C.

· Thermal resistance: 500°C/W junction to ambient.

· Lead-free finish and RoHS compliant (indicated by "P" suffix).

· Epoxy meets UL 94 V-0 flammability rating.

· Moisture Sensitivity Level 1.

· Low diode capacitance and forward resistance.

· Halogen-free, classified as a "Green" device.

APPLICATIONS

· Suitable for general-purpose applications requiring pin diodes.

· Ideal for use in environments requiring RoHS compliance and halogen-free components.
