DESCRIPTION

· The MLX90640 is a fully calibrated 32x24 pixels thermal IR array in a standard 4-lead TO39 package with a digital interface.
· It includes 768 FIR pixels, an ambient sensor for chip temperature, and a supply sensor for VDD measurement.
· Sensor outputs (IR, Ta, VDD) are stored in internal RAM and accessible via I2C.

FEATURES

· Compact and cost-effective 32x24 IR array.
· Easy integration with industry-standard TO39 package.
· Factory calibrated with a NETD of 0.1K RMS at 1Hz.
· I2C compatible interface with programmable refresh rates from 0.5Hz to 64Hz.
· Operates at 3.3V with less than 23mA current consumption.
· Offers two FOV options: 55°x35° and 110°x75°.
· Operates in temperatures from -40°C to 85°C, targeting -40°C to 300°C.
· RoHS compliant.

APPLICATIONS

· High precision non-contact temperature measurement.
· Intrusion and movement detection.
· Presence detection and person localization.
· Temperature sensing in intelligent building air conditioning.
· Thermal comfort sensor in automotive air conditioning systems.
· Microwave ovens and industrial temperature control of moving parts.
· Visual IR thermometers.
· Driver software for MCU available on GitHub.
