Name: T820081404DH
Brand: Powerex Inc.
SKU: JM-T820081404DH
Availability: InStock

Powerex Inc. T820081404DH

View All SCRs by Powerex Inc.

Part Number:
T820081404DH
Manufacturer:
Powerex Inc.
Category:
SCRs
RoHs:
RoHS Compliant
Datasheet:
T820081404DH_Datesheet
Description:
SCR 800V 2576A HOCKEY PUCK
In stock 0

" Not available to buy online? Want the lower wholesale price? Please send RFQ, we will respond immediately

Leave Us A Message!

[email protected]

We`re not around but we still want to hear from you! Leave us a note:

SEND

*You can contact us directly on WhatsApp!

Specifications

Type

Paramete

Type

Paramete

Voltage - On State (Vtm) (Max)

1.2 V

Voltage - Off State

800 V

Current - Hold (Ih) (Max)

Supplier Device Package

Hockey Puck

Current - Gate Trigger (Igt) (Max)

150 mA

Qualification

Mounting Type

Clamp On

Current - Non Rep. Surge 50, 60Hz (Itsm)

17253A, 18300A

Current - On State (It (RMS)) (Max)

2576 A

Package / Case

TO-200AB, A-PUK

Voltage - Gate Trigger (Vgt) (Max)

3 V

Operating Temperature

-20°C ~ 140°C (TJ)

SCR Type

Standard Recovery

Current - On State (It (AV)) (Max)

1640 A

Current - Off State (Max)

150 mA

Grade

Overview

DESCRIPTION

· The T820 SCR features a Center-Fired amplifying gate structure, enabling reliable operation under high di/dt and high dv/dt conditions in phase control applications.

FEATURES

· Low On-State Voltage

· High di/dt Capability

· High dv/dt Capability

· Hermetic Ceramic Package

· Excellent Surge and I²t Ratings

APPLICATIONS

· DC Power Supplies

· Plating Supplies

· Welding Supplies
