DESCRIPTION

· Ultra Small Surface Mount Package with Minimal Height of 2.5 mm

· Operates with Vcc from 2.7 to 3.6 Volts, withstanding > 250 mV p-p Power Supply Ripple

· LED Supply Voltage ranges from 2.7 to 6.0 Volts

· Features Low Shutdown Current of 20 nA Typical

· Compliant with IrDA 1.2 Low Power Standard at 115.2 kb/s

FEATURES

· Complete Shutdown capability for TxD, RxD, and PIN Diode

· Requires only one optional external component

· Operates in a temperature range from -25°C to 85°C

· Provides 32 mA LED Drive Current

· Integrated EMI Shield for enhanced performance

· Complies with IEC825-1 Class 1 Eye Safety standards

· Edge Detection Input to prevent long LED turn on time

APPLICATIONS

· Suitable for Cell Phones, Pagers, PDAs, Cameras, Printers, and PCs

· Effective for communication with Low Power Devices up to 20 cm and Standard Devices up to 30 cm
