RC0805JR-07100KL Model Information

Part Number: RC0805JR-07100KL

Product Overview:

• Series: RC_L
• Description: General Purpose Chip Resistor
• Size: 0805
• Tolerance: ±5% (J)
• Packaging Type: 7-inch dia. Reel (R)
• Temperature Coefficient of Resistance: Based on specification
• Power Rating: 1/8 W
• Operating Temperature Range: -55°C to +155°C
• Resistance Value: 100KΩ
• Termination: RoHS compliant, matte tin on Ni-barrier
• Compliance: RoHS compliant & Halogen free
• Features:
• High component and equipment reliability
• Saving of PCB space
• No forbidden materials used in products/production
• MSL class: MSL 1
• Reducing environmentally hazardous wastes
• Applications:
• All general-purpose applications
• Suitable for high-precision and high-reliability requirements
• Construction:
• The resistor is constructed on top of a high-grade ceramic body.
• Internal metal electrodes are added on each end to make the contacts to the thick film resistive element.
• The resistive element is composed of a noble metal embedded in glass and covered by a second glass layer to prevent environmental influences.
• The resistor is laser-trimmed to the rated resistance value.
• The resistor is covered with a protective epoxy coat.
• External terminations are added (matte tin on Ni-barrier).
• Dimensions:
• Length (L): 2.00 mm ± 0.10 mm
• Width (W): 1.25 mm ± 0.10 mm
• Height (H): 0.50 mm ± 0.10 mm
• I1: 0.35 mm ± 0.20 mm
• I2: 0.35 mm ± 0.20 mm
• Electrical Characteristics:
• Power Rating: 1/8 W
• Operating Temperature Range: -55°C to +155°C
• Maximum Working Voltage: 150V
• Maximum Overload Voltage: 300V
• Dielectric Withstanding Voltage: 300V
• Resistance Range: 1Ω ≤ R ≤ 100MΩ
• Temperature Coefficient: ± 200ppm/°C
• Jumper Criteria: <50mΩ
• Marking:
• For 1%, 0.5%, E24/E96 series: 4 digits (first three digits for significant figure and fourth digit for number of zeros)
• For 5%, E24 series: 3 digits (first two digits for significant figure and third digit for number of zeros)
• Ordering Information:
• Global Part Number: RC0805JR-07100KL
• Ordering Example: RC0805JR-07100KL (100KΩ, ±5% tolerance, 7-inch tape reel)
• Packaging:
• 7-inch dia. Reel (R)
• Standard power rating
• Quantity per reel: Refer to the specific packaging details in the datasheet
