Honeywell RTY180LVEAX
- Part Number:
RTY180LVEAX
- Manufacturer:
- Category:
- RoHs:
RoHS Compliant - Datasheet:
RTY180LVEAX_Datesheet - Description:
SENSOR ROTARY 180DEG CONNECTOR
- In stock 0
RTY180LVEAX Model Information
The following details pertain to the RTY180LVEAX model as outlined in the provided Honeywell datasheet:
General Description
- Series: RTY Series
- Type: Hall-effect Rotary Position Sensor
- Actuator Type: Integral shaft with lever
Key Features
- True, non-contact operation
- Solid-state Hall-effect technology
- Rugged IP69K-sealed package with integral connector
- Automotive-grade EMI/EMC testing, integrated reverse polarity, and short circuit protection
- Industry-standard AMP termination, 32 mm mounting pitch, North American or European pinout styles, and compact package
- Eight operating ranges up to 360°
Mechanical Specifications
- Expected Life: 35 M cycles
- Air Gap: 3.00 mm ± 0.5 mm [0.12 in ± 0.02 in]
- Material:
- Mating Connector: AMP Superseal 282087-1
- Mounting Screw Sizes:
Electrical Specifications
- Supply Voltage: 5 Vdc
- Supply Current:
- Output:
- Output Signal Delay: 4 ms typ.
- Overvoltage Protection: 10 Vdc
- Reverse Polarity Protection: -10 Vdc
- Output to Ground Short Circuit Protection: continuous
- Resolution: 12 bit
- Output Load Resistance (pull down to ground): 10 kOhm typ.
Environmental Specifications
- Operating Temperature Range: -40 °C to 125 °C [-40 °F to 257 °F]
- Ingress Protection: IP69K
- Media Compatibility: Heavy transportation fluids
- Shock: 50 G peak
- Vibration: 20 G peak
- Salt Fog: 5% ±1% for 240 hr per SAE J1455 Section 4.3.3.1
Product Nomenclature
- RTY180LVEAX:
