Description of FFC and FPC Connector Housings

FFC and FPC connector housings serve the purpose of mounting and safeguarding the components of flat flexible connectors. Constructed primarily from plastic or metal, they are tailored to be compatible with specific FFC or FPC connectors, guaranteeing stability and protection of the connectors. These housings frequently feature guide slots, locking mechanisms, and mounting holes to ensure the connection is both secure and reliable.

FFC and FPC connector housing

Features of FFC and FPC Connector Housings

The characteristics of FFC and FPC connector housings include the number of positions they accommodate, their pitch, the number of rows, and the type of cable they can accept. In terms of materials, these housings can be made from polyamide, polybutylene, polyester, or thermoplastic.

Main Functions of FFC and FPC Connector Housings

FFC housings are equipped with a pre-assembled FFC cable before being connected to a board side header  or another FFC cable. These housings come in various styles, including standard or slimline, single or dual row, with optional latching features, and with or without mounting ears for installation.
