Logic Output Photo Detectors are photodetectors that transform light signals into digital signals (logic high or logic low). These sensors are commonly employed in applications that require distinct switch states, including object detection, light gates, automation control, and security systems. They are known for their high accuracy, rapid response, and straightforward integration, making them popular in industrial automation, consumer electronics, and smart home applications.

What is Photodetector?

A photodetector is defined as an optoelectronic device designed to detect incoming light or optical power and convert it into an electrical signal. Typically, this output signal is proportional to the incident optical power. These sensors are essential for various scientific applications, including process control, fiber optic communication systems, safety, environmental monitoring, and defense. Examples of photodetectors include phototransistors and photodiodes.

Working of Photodetector

The fundamental principle of a photodetector is that when incident light or radiation strikes its surface and is absorbed, it is converted into electrical signals.

A photodetector functions as a reverse-biased p-n junction. Here’s how it operates:

There are three processes involved in the functioning of the photodetector:

Absorption

In this stage, light energy strikes the photodetector and is absorbed. Light consists of small energy packets known as photons, and multiple photons are absorbed by the photodetector. This leads to:

• The generation of charged carriers within the device.
• The creation of electron-hole pairs (e- and h+).

Transportation of Carriers

Here, the generated charge carriers move through the absorption regions. In some photodetectors, the carriers receive a gain, resulting in the multiplication of photons during their transport.

Extraction of Carriers as Photocurrent

Once the charged particles (electron-hole pairs) are successfully transported, they are collected, and the resulting current flows through the external circuit as an electrical signal. This current is primarily generated by the photons hitting the photodetector, which is why it is referred to as photocurrent.
