DESCRIPTION

· The AP62300/AP62301/AP62300T is a 3A synchronous buck converter with a 4.2V to 18V input range.

· It integrates 75mΩ high-side and 45mΩ low-side MOSFETs for efficient DC-DC conversion.

· Uses Constant On-Time (COT) control for fast response and low ripple.

· Optimized for EMI reduction with a proprietary gate driver scheme.

· Available in SOT563 and TSOT26 packages.

FEATURES

· Input voltage: 4.2V to 18V.

· Output voltage: 0.8V to 7V.

· 3A continuous output current.

· 0.8V ± 1% or 0.763V ± 1% reference voltage.

· 155μA quiescent current.

· 750kHz switching frequency.

· Up to 83% efficiency at 5mA load.

· Includes UVLO, current limit, undervoltage protection, and thermal shutdown.

· Lead-free, RoHS compliant, and halogen-free.

APPLICATIONS

· 5V and 12V power bus supplies.

· Flat screen TVs and monitors.

· White goods and home appliances.

· FPGA, DSP, and ASIC supplies.

· Home audio and network systems.

· Gaming consoles and consumer electronics.

· General-purpose point of load.
