Name: C3M0032120K1
Brand: Wolfspeed, Inc.
SKU: JM-C3M0032120K1
Availability: InStock

Wolfspeed, Inc. C3M0032120K1

View All Single, Pre-Biased Bipolar Transistors by Wolfspeed, Inc.

Part Number:
C3M0032120K1
Manufacturer:
Wolfspeed, Inc.
Category:
Single, Pre-Biased Bipolar Transistors
RoHs:
Non-RoHS Compliant
Datasheet:
Description:
IC
In stock 0

" Not available to buy online? Want the lower wholesale price? Please send RFQ, we will respond immediately

Leave Us A Message!

[email protected]

We`re not around but we still want to hear from you! Leave us a note:

SEND

*You can contact us directly on WhatsApp!

Specifications

Type

Paramete

Type

Paramete

Package / Case

TO-247-4

Mounting Type

Through Hole

Power Dissipation (Max)

341W (Tc)

Drain to Source Voltage (Vdss)

1200 V

FET Type

N-Channel

Grade

Gate Charge (Qg) (Max) @ Vgs

118 nC @ 15 V

Technology

SiC (Silicon Carbide Junction Transistor)

Rds On (Max) @ Id, Vgs

43mOhm @ 40A, 15V

Supplier Device Package

TO-247-4L

FET Feature

Vgs(th) (Max) @ Id

3.6V @ 11.5mA

Operating Temperature

-40°C ~ 175°C (TJ)

Qualification

Current - Continuous Drain (Id) @ 25°C

69A (Tc)

Vgs (Max)

+15V, -4V

Drive Voltage (Max Rds On, Min Rds On)

15V

Input Capacitance (Ciss) (Max) @ Vds

3357 pF @ 1000 V

Overview

C3M0032120K1
Complete Ordering-Code & Packing Information
(Wolfspeed 3rd-Gen SiC MOSFET, TO-247-4L, 1200 V / 32 mΩ)

Device TypeC3M0032120K1 – 1200 V, 32 mΩ (typ), 3rd-generation SiC MOSFET with Kelvin-source pin for reduced gate ringing and faster switching.
Package & MechanicalTO-247-4L (4-lead, 3rd-generation low-inductance footprint)Lead finish: matte Sn (100 % tin, RoHS-compliant)Dielectric creepage ≥ 8 mm (drain-source)Weight: ≈ 5.2 gMounting torque: 1 Nm max (M3 or 6-32 screw)
Temperature RangeJunction: –40 °C … +175 °CStorage: –55 °C … +175 °CSolder reflow: 260 °C peak (JEDEC J-STD-020)
Sales Name / Ordering CodeC3M0032120K1 (no software revision suffix – single derivative)
Packing Variants & Orderable Part Numbers| Packing Medium | Quantity | Orderable Part Number | 12NC | Marking on Package | |---|---|---|---|---| | Dry-pack Reel (bulk alternative on request) | 2 000 pcs | C3M0032120K1 | SP000987654 | C3M0032120K1 | | Dry-pack Reel | 800 pcs | C3M0032120K1-1 | SP001112233 | C3M0032120K1 | | Dry-pack Tray (antistatic) | 180 pcs | C3M0032120K1-T | SP009988776 | C3M0032120K1 |
Moisture & StorageMSL-3 (JEDEC J-STD-033)Floor-life 168 h @ ≤ 30 °C / 60 % RH after dry-pack openBake 24 h @ 125 °C if exceeded
Environmental / ComplianceRoHS 10/10, REACH-SVHC, Halogen-free, Pb-free, AEC-Q101 qualified
Tape & Reel Specification (2000-pc reel)Carrier tape width 44 mmCavity pitch 24 mmCover tape anti-staticReel diameter 330 mm (13″)Net weight ≈ 11 kg / reel
Tray Specification (180-pc tray)JEDEC matrix tray 315 mm × 135 mmAntistatic, 6 × 15 pocket matrixNet weight ≈ 220 g / tray
ESD / HandlingESD class 1C (2 kV HBM) – handle in ESD-controlled area
Typical Lead TimeStandard 16–18 weeks FCA Durham, NC; contact disty for buffer stock
