Product Description: STMicroelectronics STM32F103C8T6

The STM32F103C8T6 is a microcontroller from the STM32 series of 32-bit ARM Cortex-M3-based microcontrollers by STMicroelectronics. Designed for cost-effective, low-power applications, the STM32F103C8T6 offers an optimal balance of performance and power efficiency. It is ideal for a wide range of embedded applications, including industrial, automotive, consumer electronics, and home automation.

Product Features:

• Core: ARM Cortex-M3 32-bit RISC processor running at up to 72 MHz.
• Flash Memory: 64 KB of Flash memory for program storage.
• RAM: 20 KB of SRAM for data storage and runtime operations.
• Peripherals:
• Operating Voltage: 2.0 V to 3.6 V, suitable for low-power designs.
• Low Power Consumption: Various power-saving modes, including Sleep and Stop modes, ideal for battery-operated devices.
• Integrated Debugging Interface: Supports JTAG and SWD for debugging and programming.
• Package: Available in a 48-pin LQFP (Low-Profile Quad Flat Package), making it suitable for compact designs.

Applications:

• Consumer Electronics: Ideal for embedded systems in consumer devices such as remote controls, home appliances, and wearable technology.
• Industrial Automation: Perfect for industrial control systems, including automation, sensors, and motor control.
• Automotive: Suitable for automotive applications like in-vehicle sensor systems, display controls, and communication interfaces.
• Home Automation: Used in smart home devices such as lighting control systems, thermostats, and security sensors.
• IoT (Internet of Things): Well-suited for IoT applications requiring wireless communication, sensor integration, and low power consumption.
• Embedded Systems: Can be integrated into custom embedded systems for various applications like robotics, control systems, and sensor-based devices.

Frequently Asked Questions (FAQs):

1. What is the clock speed of the STM32F103C8T6?
The STM32F103C8T6 is powered by the ARM Cortex-M3 processor, which can operate at speeds up to 72 MHz.

2. How much flash memory does the STM32F103C8T6 have?
The STM32F103C8T6 has 64 KB of Flash memory for storing program code.

3. Can I use STM32F103C8T6 in low-power applications?
Yes, the STM32F103C8T6 features several low-power modes, including Sleep and Stop modes, making it ideal for battery-powered applications.

4. What communication interfaces are available on the STM32F103C8T6?
The microcontroller supports a variety of communication protocols, including USART, SPI, and I2C, for interfacing with peripherals and other devices.

5. How much RAM does the STM32F103C8T6 have?
The STM32F103C8T6 is equipped with 20 KB of SRAM for temporary data storage and runtime operations.

6. Is the STM32F103C8T6 suitable for motor control?
Yes, the STM32F103C8T6 features PWM outputs and timers, making it suitable for motor control and other time-dependent applications.

7. How is the STM32F103C8T6 programmed?
Programming and debugging of the STM32F103C8T6 can be done using the integrated JTAG or SWD interface, providing easy access to debugging and flashing your program.
