What are Pre-biased bipolar transistors?

Pre-biased bipolar transistors include internal resistors that keep the device close to its bias or operating point when no input signal is present. This biasing enables the transistor to function more efficiently and generate a stable, undistorted output signal. Additionally, pre-biased transistors minimize the need for external circuit components, leading to lower project costs.
