Product Description: NXP MK64FN1M0VLQ12

The NXP MK64FN1M0VLQ12 is a microcontroller from the Kinetis K series by NXP Semiconductors. It is built on the ARM Cortex-M4 core, providing high performance with a balance of low power consumption and rich features. The MK64FN1M0VLQ12 is designed for embedded applications requiring high processing power, connectivity, and real-time control. It is ideal for industrial, automotive, and consumer electronic systems where precision, performance, and power efficiency are essential.

Product Features:

• ARM Cortex-M4 Core: The MK64FN1M0VLQ12 is powered by an ARM Cortex-M4 processor with FPU (Floating Point Unit), running at a speed of up to 120 MHz. This provides high computational power for signal processing, control, and embedded applications.
• Memory:
• Flash Memory: 1 MB of Flash memory for code storage, providing ample space for large applications.
• SRAM: 256 KB of SRAM to store data and temporary variables, supporting complex operations and large data buffers.
• Connectivity:
• Ethernet MAC (10/100 Mbps): Allows the MCU to communicate over Ethernet networks, ideal for IoT, industrial control, and connected devices.
• Multiple UARTs, SPI, I2C: The MK64FN1M0VLQ12 supports multiple serial communication interfaces, including UART, SPI, and I2C, enabling easy integration with sensors, peripherals, and other devices.
• CAN Bus: Built-in CAN (Controller Area Network) support makes it suitable for automotive and industrial communication.
• Analog Features:
• 12-bit ADC: The microcontroller includes a 12-bit Analog-to-Digital Converter (ADC) for precise analog signal processing.
• DAC and Comparators: Features an integrated Digital-to-Analog Converter (DAC) and comparators for real-time control applications.
• Low Power Consumption: The MK64FN1M0VLQ12 is optimized for low-power operation with several low-power modes, including sleep and deep sleep modes, making it ideal for battery-operated or energy-sensitive applications.
• Timers and PWM: Includes multiple timers, PWM outputs, and watchdog timers, supporting real-time control applications such as motor control, power regulation, and sensor interfacing.
• Security Features: The device includes hardware CRC (Cyclic Redundancy Check) for data integrity, as well as security features for embedded applications that require data protection.
• Package Type: The MK64FN1M0VLQ12 is offered in an LQFP-64 (Low-profile Quad Flat Package) with 64 pins, which allows for a compact footprint while providing sufficient I/O for a wide variety of applications.
• Temperature Range: The device operates within a temperature range of -40°C to +105°C, making it suitable for automotive and industrial environments.

Applications:

• Industrial Control Systems: The MK64FN1M0VLQ12 is ideal for industrial automation, motor control, robotics, and sensor interfaces, providing the computational power and connectivity required for real-time control.
• Automotive Electronics: The microcontroller is well-suited for automotive applications, including in-vehicle networks (CAN), telematics, diagnostics, and infotainment systems.
• IoT (Internet of Things): With Ethernet, serial communication, and low-power modes, the MK64FN1M0VLQ12 is an excellent choice for IoT devices requiring reliable communication and low energy consumption.
• Consumer Electronics: This MCU is used in applications such as home automation, smart appliances, and wearable devices, where both performance and energy efficiency are key.
• Medical Devices: Its analog features (ADC, DAC) and precision control make it suitable for medical devices that require accurate data acquisition and processing.

Frequently Asked Questions (FAQs):

1. What is the clock speed of the NXP MK64FN1M0VLQ12?
The MK64FN1M0VLQ12 runs at a clock speed of up to 120 MHz, providing high processing power for real-time and computationally intensive applications.

2. How much Flash memory does the MK64FN1M0VLQ12 have?
The MK64FN1M0VLQ12 has 1 MB of Flash memory, offering ample space for storing firmware, application code, and data.

3. What communication interfaces does the MK64FN1M0VLQ12 support?
The microcontroller supports multiple communication interfaces, including UART, SPI, I2C, Ethernet, and CAN, making it suitable for a wide range of applications in industrial, automotive, and consumer devices.

4. What is the resolution of the built-in ADC?
The MK64FN1M0VLQ12 has a 12-bit ADC, allowing for precise analog-to-digital conversion, which is important for sensor applications, signal processing, and control systems.

5. Can the MK64FN1M0VLQ12 be used in low-power applications?
Yes, the MK64FN1M0VLQ12 is designed for low-power operation with features such as sleep modes and deep sleep modes, making it suitable for battery-powered and energy-sensitive devices.

6. What is the operating temperature range of the MK64FN1M0VLQ12?
The MK64FN1M0VLQ12 operates within the temperature range of -40°C to +105°C, making it suitable for use in automotive and industrial environments that require wide temperature tolerance.

7. What is the package type for the MK64FN1M0VLQ12?
The MK64FN1M0VLQ12 comes in a 64-pin LQFP (Low-profile Quad Flat Package), which provides a compact and flexible solution for a variety of embedded designs.
